| Brand Name: | JYK |
| Model Number: | 820 |
| MOQ: | 1pc |
| Price: | 200USD-260USD |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union |
| Supply Ability: | 1000pcs/month |
Medical infusion pump BYS-820 is an advanced automatic portable infusion syringe pump designed for pediatric and general medical use. This volumetric infusion pump combines precision engineering with user-friendly features for safe and reliable medical injections.
| Feature | Specification |
|---|---|
| Infusion Rate | 1ml/h - 1,200ml/h |
| Flow Rate Accuracy | Within ±5% (after correct calibration) |
| Mechanical Precision | Within ±2% |
| Purge Rate | 100ml/h - 1,000ml/h (100 ml/h step) |
| Infusion Volume | 1ml - 9999ml |
| Total Infusion Volume | 0.1ml - 9999.9ml |
| KVO Rate | 1ml/h - 5 ml/h (1ml/h step) |
| Occlusion Pressure | High: 800mmHg ±200mmHg (106.7kPa±26.7kPa) Medium: 500mmHg ±100mmHg(66.7kPa±13.3kPa) Low: 300mmHg ±100mmHg (40.7kPa±13.3kPa) |
| Alarm System | End of injection, occlusion, door open, bubbles in tube, wrong setting, low battery, AC power disconnect |
| Power Source | AC 100V-240V, 50/60Hz; Internal rechargeable Li battery (≥1,600mAh), 4 hours battery backup |
| Bubble Detector | Ultrasonic wave detector; detection sensitivity ≥25μL |
| Fuse | F1AL/250V, 2 pieces included |
| Power Consumption | 30VA |
| Operating Conditions | Temperature: +5°C to +40°C Humidity: 20-90% RH Pressure: 86.0kPa - 106.0kPa |
| Storage & Transport | Temperature: -30°C to +55°C Humidity: ≤95% RH |
| Equipment Classification | Class I, internal power supply, Type CF |
The unique Human Voice Alarm system provides clear audio prompts and automatically stops injection when malfunctions are detected, ensuring the infusion process remains safe and reliable throughout operation.
