| Brand Name: | JYK |
| Model Number: | 810TU |
| MOQ: | 1pc |
| Price: | 500USD-600USD |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union |
| Supply Ability: | 1000pcs/month |
| Rate | 50/60ml Syringe: 0.1ml/h-999.9ml/h (0.1ml/h step), 1,000ml/h-1,500ml/h (1ml/h step) 30ml Syringe: 0.1ml/h-900.0ml/h (0.1ml/h step) 20ml Syringe: 0.1ml/h-600.0ml/h (0.1ml/h step) 10ml Syringe: 0.1ml/h-300.0ml/h (0.1ml/h step) |
|---|---|
| Flow Rate Accuracy | Within ±3% (after correct calibration) |
| Mechanical Precision | Within ±2% |
| Bolus Rate | 50/60ml Syringe: 1,200ml/h 30ml Syringe: 720ml/h 20ml Syringe: 480ml/h 10ml Syringe: 240ml/h |
| Purge Rate | 50/60ml Syringe: 1,500ml/h 30ml Syringe: 900ml/h 20ml Syringe: 600ml/h 10ml Syringe: 300ml/h |
| Volume Limit | 0.1ml-999.9ml |
| Total Injection Volume | 0.1ml-9999.9ml (0.1ml step) |
| Occlusion | High: 800mmHg ±200mmHg (106.7kPa±26.7kPa) Medium: 500mmHg ±100mmHg (66.7kPa±13.3kPa) Low: 300mmHg ±100mmHg (40.7kPa±13.3kPa) |
| Alarms | Injection soon finish, end of injection, occlusion, improperly installation of syringe, wrong setting, low battery, syringe loose etc. |
| Power Source | AC 100V-240V, 50/60Hz; Internal rechargeable Li battery, capacity≥1,600mAh, 4 hours internal battery backup |
| KVO Rate | 1ml/h |
| Fuse | F1AL/250/60V, 2pcs inside |
| Power Consumption | 30VA |
| IP Classification | IPX1 |
| Equipment Classification | Class I, internal power supply, Type CF |
| Operating Condition | Ambient temperature: +5°C to +40°C Relative humidity: 20-90% |
| Transport & Storage Condition | Ambient temperature: -30°C to +55°C Relative humidity: ≤95% |
| Dimension | 280mm (L) × 210mm (W) × 130mm (H) |
| Weight | 2.2kg (net weight) |
