Aluminum Electric Hydraulic Stretcher Chair Position Patient Trolley Sit-to-Lie Conversion 4-Actuator 200kg

Brand Name:	JYK
Model Number:	JYK-B329CH
MOQ:	1 Piece
Price:	USD 2600-3200 / Piece
Payment Terms:	T/T, L/C, Western Union, D/A, D/P
Supply Ability:	250 Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

ISO 13485 CE

Material:

6061-T6 Aluminum Alloy Anodized

Actuators:

4 Independent Electric With Feedback

Conversion:

Sit-to-lie Electric Synchronized

Memory:

3 Programmable Position Presets

Safety:

Anti-entrapment Obstruction Sensors

Armrests:

Flip-up Padded With Control Panel

Packaging Details:

JYK branded carton with actuator protection, export-grade outer carton

Supply Ability:

250 Pieces per Month

Highlight:

Aluminum electric hydraulic stretcher chair

Patient trolley with sit-to-lie conversion

4-actuator stretcher chair 200kg capacity

Product Description

Aluminum Electric Hydraulic Stretcher Chair Position Patient Trolley 200kg

Innovative convertible stretcher-chair patient trolley featuring four independent electric actuators for complete positioning freedom. Model JYK-B329CH transforms from a flat stretcher to a comfortable chair position, enabling both transport and seated procedures in a single device.

Product Overview

Convertible stretcher-chair with electric sit-to-lie transformation
Model number: JYK-B329CH
Stretcher dimensions: 2100*760*480/820mm
Maximum loading capacity: 200kg

Construction Materials

Frame: 6061-T6 aluminum alloy with anodized finish
Actuators: 4 independent electric linear actuators with position feedback
Seat platform: Contoured aluminum with pressure-distributing foam
Armrests: Flip-up padded aluminum with integrated control panel

Key Features

Sit-to-lie conversion via synchronized 4-actuator electric system
Chair position enables seated procedures, feeding, and patient interaction
Independent backrest, seat, leg rest, and foot rest actuator control
Memory function stores 3 frequently used position configurations
Flip-up armrests with integrated wired handset docking
Aluminum frame offers strength with reduced overall weight
Central lock castors with directional tracking wheel
Anti-entrapment sensors stop movement if obstruction detected

Technical Specifications

Feature	Specification
Backrest Range	0-85° (flat to upright chair)
Seat Angle	0-15° electric tilt
Leg Rest Range	0-90° (horizontal to dependent)
Height Range	480-820mm electric
Actuator Count	4 independent electric
Memory Positions	3 programmable presets
Safety Feature	Anti-entrapment obstruction sensors
Castors	4pcs 150mm central lock + directional

Applications

Ideal for dialysis units, chemotherapy infusion centers, and outpatient procedure rooms where patients benefit from chair positioning during treatment. The convertible design eliminates the need to transfer patients between a stretcher and procedure chair.
