Electric hospital double-arm ICU pendant designed for operation rooms, featuring advanced medical pendant systems with single and double arm configurations for ICU applications.

Key Features

Medical equipment model: M600B double-arm ICU pendant
Power supply: AC220V, 50Hz, input power: 4kVA
Arm rotary radius: 750+750mm
Horizontal rotation: 0-340°, arm and pendant body rotate simultaneously or separately
Pneumatic brake system prevents drifting, easy movement (requires compressed air)
Loading capacity: 80-150kg

Instrument & Gas Systems

Instrument shelves: 3 pieces (height adjustable)
Fillet design to avoid collision, ultra-thin design to save space
High-strength aluminum material construction
Gas outlets: O2 (2), vacuum (2), compressed air (1), CO2 (1)
Color and shape coding to prevent wrong attachments
Service life: 20,000 cycles
Second sealing system with three states: connecting, close, pullout
Repairable while connected to gas source

Electrical & Accessory Features

Power sockets: 6 pieces, 220V, 10A
Ground terminals: 2 pieces
Drawer: 1 piece
RJ45 network connection: 1 piece
Stainless steel drip hanger: 1 piece
Stainless steel infusion pump shelf: 1 piece

Construction & Options

Material: High-strength aluminum alloy
Electrostatic coating finish
Ceiling mounted design with stable, firm construction
Weight: 170kg
Optional accessories: Instrument shelves, gas outlets, storage basket, VGA connector, intercom device, telephone connector, power sockets, grounding terminal

Technical Specifications

Specification	Details
Power supply	AC220V, 50Hz, input power: 4kVA
Arm rotary radius	750+750mm
Horizontal rotation	0-340°, arm and pendant body rotates simultaneous or separately
Pneumatic brake	Yes
Instrument shelves	3 pieces (height adjustable)
Gas outlets	O2: 2, vacuum: 2, compressed air: 1, CO2: 1

Product Images
